Alu.Inlay

Material

Paper+ PVC+ PET

Thickness

Antenna position: 0.35mm

IC position: 0.55mm

Format

5*5=25 cards/sheet

Bonding method

Wire Bonding

Operating temperature

-20°C ~+70°C/-25°C~+85°C

Storage Temperature

-20°C ~+65°C

Data Retention

5 years/10 years (at +55°C )

Chip Bonding

Wire bonding

Operating Frequency

LF 125MHz (ISO/IEC 11784/85, ISO/IEC 18000-3)

HF 13.56MHz (ISO/IEC 14443 A/B, ISO15693)

UHF 860~960MHz (ISO/IEC 18000-6C, EPC Global Class 1 Gen 2)

IC chips

13.56MHz:

NXP Mifare 1K 4K, NTAG 213/216, Utralight EV1/ C, Fudan 1K compatible; Fudan 4K compatible, I-CODE SLI, etc.

860~960MHz:

UCODE GEN2,  Alien H3,  Impinj M4
